六面顶液压机适用于人造金刚石、立方氮化硼的单晶和聚晶,以及合成复合片(PCD、PCBN)等超硬材料领域的研发和生产制造。针对客户的个性需求,提供全套的工装、液压解决方案。

The cubic press is applicable to the research and development, the production and manufature of the super-hard materials, including the artificial diamond, the monocrystal and glomerocryst of CBN (cubic boron nitride), and the synthesized compounds (such as PCD,PCBN) and etc. Aiming at the customer individual requirements of customization, we are able to provide the whole set of auxiliaries and hydraulic solutions.


压机

本机采用无动力泄荷方式, 采用双高压油泵供油,并通过管路通径、阀板通径、阀件通径的优化设计、合理调配,实现空程前进、超压、快速回程不同调速需要。超高压系统采用两台超高压泵超压、补压,可以实现长时间保压,并采用伺服电机泄压阀,实现连续、平滑、可控泄压。

The hydraulic unit is able to greatly meet the requirement of speed regulation among the different processes,such as idle stroke, super pressure, and rapid return stroke , via umpowered pressure relief, oil feeding by two high-pressure pumps , and alsovia optimal design and rational deployment on the diameters of pipes, valve plates and valves. The super pressure system is equipped with two super pumps to super-pressurization and supplement, which also can fulfill a long-time pressure maintenance. Using servo pressure relief can make the process of pressure relief continuous, smooth and controllable.

电控

采用先进的控制理念,模拟信号采集、信号转换和信号控制,具有各种保护功能和记忆功能,压力和功率曲线多段控制,非常适合不同的合成工艺调节。电加热方面,提供了恒功率、恒电压和恒电流多种控制方式。

The electronic control system using an advanced control philosophy, has the functions of simulating signal acquisition, signal transformation, signal control, and also kinds of protection and memory functions. Using multistratum control of pressure and function curves, the system can adapt to different conditions of synthetic process. On the aspect of electrical heating, it provides several control ways, such as constant power, constant voltage, and constant current etc.

工装

根据客户需求设计并提供特殊定制的工装部件(顶锤、钢环、大垫块等)。

Provide the customized accessories(such as anvils, steel rings, pads and etc.) according the customer's design demand.

合成块

提供优质可靠的叶腊石合成块及其组件。

Provide high-quality and reliable pyrophyllite block, as well as its components.

我们的产品/Our products

参数选择/Parameter selection

推荐数/Recommended models

铰链梁内径/Hinge beams inner diameter

铰链梁类型/Hinge beams structure

单缸推力/Individual cylinder stretch

额定压力/Nominal pressure,mPa

加热功率/Heating power, KVA

产品类型/For creating products
